Telecentric Lenses

Need Help?
Looking for
Custom Optics?

Category
    Primary Magnification PMAG
    Maximum Sensor Format
    Working Distance (mm)
    Mount
    Type
    Style
    CompactTL™ Telecentric Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
    CompactTL™ Telecentric Lenses
    • Ultra-Compact Design
    • Ideal for Volume Inspection Applications
    • Variety of Working Distance and Magnification Options
    SilverTL™ Telecentric Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
    SilverTL™ Telecentric Lenses
    • <0.1° Telecentricity
    • Double Sided Telecentric Designs
    • High Light Throughput f/6 Designs
    • Designed for ½” and 2/3” Sensor Formats
    GoldTL™ Telecentric Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
    GoldTL™ Telecentric Lenses
    • Focusable to Allow for Working Distance Adjustment
    • High Light Throughput f/6 Designs
    • Designed for ½” and 2/3” Sensor Formats
    • <0.2° Telecentricity
    PlatinumTL&trade; Telecentric Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
    PlatinumTL™ Telecentric Lenses
    • <0.1° Telecentricity
    • High Contrast at 72 lp/mm Across Full Sensor Field
    • High Light Throughput f/6 Designs
    • Double Sided Telecentric Design
    TitanTL&trade; Telecentric Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
    TitanTL™ Telecentric Lenses
    • Large Field of View Options up to 242mm
    • Sensor Formats: 1/1.8”, 2/3”, 1”, 4/3”, and 35mm
    • <0.1° Telecentricity
    Hypercentric Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
    Hypercentric Lenses
    • Simultaneously Image Top and Sides of an Object
    • Can Be Used as Long Working Distance Borescopes
    • Ideal for Component Inspection
    VariMagTL&trade; Telecentric Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
    VariMagTL™ Telecentric Lenses
    • Adjustable Field of View
    • Variable Iris to Control Light Throughput
    • Fixed Magnification, Telecentric, and Non-Telecentric Versions Available
    MercuryTL&trade; Liquid Lens Telecentric Lenses
    TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
    New
    ×
    MercuryTL™ Liquid Lens Telecentric Lenses
    • Integrated Liquid Lens for Quick Autofocus
    • Imaging Performance of a Telecentric with the Flexibility of a Liquid Lens
    • Telecentricity Maintained Throughout Working Distance Range
    55mm FL Partially-Telecentric Imaging Lens 55mm FL Partially-Telecentric Imaging Lens
    • Telecentric Lenses Yield Constant Magnification over a Range of Working Distances
    • ±12.5mm of Object Movement Before 1% Error Image Scale Occurs
    • Additional Lens Converter Available
    High Resolution In-Line Illumination C-Mount Telecentric Lenses High Resolution In-Line Illumination C-Mount Telecentric Lenses
    • Designed for High Resolution Imaging
    • In-line Illumination Port (0.312" Ferrule)
    • 2/3" Max. Sensor Format
    In-Line Illumination C-Mount Telecentric Lenses In-Line Illumination C-Mount Telecentric Lenses
    • Fiber Optic Input for In-line Illumination
    • Long Working Distance
    • 2/3” Max Sensor Format
    Mitutoyo Telecentric Objectives Mitutoyo Telecentric Objectives
    • Long Working Distances Allow for Integration into Machine Vision Measurement Systems
    • Compact Design and Long Parfocal Length Simplifies Mounting
    • Tube Available for Use with C-Mount Cameras
    • Aluminum Alloy Housing
    Partially-Telecentric 7X Zoom Lens Partially-Telecentric 7X Zoom Lens
    • Maintains Telecentricity from 0.25X - 0.5X
    • Variable Working Distance Range
    • Center to Corner Resolution >100 lp/mm
    Schneider Telecentric Lenses Schneider Telecentric Lenses
    • Telecentric In Image and Object Space
    • Fine Focus Adjustment of ±3mm
    • Full Iris Control
    • 2/3" Max. Sensor Format
    Variable Magnification Telecentric Lens Variable Magnification Telecentric Lens
    • 0.3X - 0.5X Magnification
    • 2/3” Maximum Sensor
    • Focus, Zoom and Iris Adjustment
    • Long Working Distance

    View all Resources Related to Telecentric Lenses

    Telecentric Lenses are used in imaging systems to make objects appear to be the same size independent of their location in space. Telecentric Lenses remove the perspective or parallax error that makes closer objects appear to be larger than objects farther from the lens, increasing measurement accuracy compared to conventional lenses. Telecentric Lenses are ideal for use in a variety of applications, including metrology, gauging, CCD based measurement, or microlithography.

    Edmund Optics’ Telecentric Lenses are available with a range of features for a variety of machine vision or inspection applications. TECHSPEC® GoldTL™ Telecentric Lenses feature focus adjustment, along with iris adjustment. TECHSPEC® SilverTL™ Telecentric Measuring Lenses includes iris adjustment in addition to a double telecentric design. TECHSPEC® CompactTL™ Telecentric Lenses feature compact designs ideal for high volume system integration. TECHSPEC® CompactTL™ Telecentric Lenses are available in in-line models. PlatinumTL™ Telecentric Lenses are also available to cover large sensor sizes.
