SCHOTT Optical Components

Custom and
Volume Manufacturing

Learn More

SCHOTT AS 87 ECO Ultra-Thin Windows SCHOTT AS 87 ECO Ultra-Thin Windows
  • High Level of Flexibility
  • Ultra-Thin Thickness for Low Profile Designs
  • Excellent Transmission from 250nm to >3µm
Chemically Strengthened SCHOTT AS 87 eco Ultra-Thin Windows Chemically Strengthened SCHOTT AS 87 eco Ultra-Thin Windows New
×
  • Enhanced Impact, Temperature, and Scratch Resistance
  • High Transmission in the Visible and NIR Spectra
  • Ideal as Cover Glass for Displays and Sensors
  • SCHOTT AS 87 eco Ultra-Thin Windows Also Available
Ultra-Thin N-BK7 Windows Ultra-Thin N-BK7 Windows
TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
New
×
  • Ultra-Thin 0.20mm Thickness
  • Precision N-BK7 Substrate
  • Extremely Lightweight
BOROFLOAT® Borosilicate Windows BOROFLOAT® Borosilicate Windows
TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
  • Low Coefficient of Thermal Expansion
  • Visible to Near Infrared Transmission
  • High Resistance to Thermal Shock
B270 Windows B270 Windows
TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
  • Large Selection of Sizes
  • Available Uncoated or with a MgF2 Anti-Reflection Coating
  • Custom Sizes Available for Volume OEM Requirements
Hydrophobic Windows Hydrophobic Windows
  • Oil and Water Repellent Coating
  • Ideal for Industrial and Harsh Environments
  • AR Coated for <0.5% Reflection in the Visible Spectrum
N-BK7 Wedged Windows N-BK7 Wedged Windows
TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
&lambda;/4 N-BK7 Laser Line Windows λ/4 N-BK7 Laser Line Windows
TECHSPEC® components are designed, specified, or manufactured by Edmund Optics. Learn More
  • <0.25% Reflection at Design Wavelength
  • Coatings Available for HeNe, Diode, and Nd:YAG Laser Sources
  • Precision N-BK7 Substrate
  • Also Available Uncoated, MgF2 Coated and VIS 0° Coated
SCHOTT Xensation® Chemically Strengthened Windows SCHOTT Xensation® Chemically Strengthened Windows
SCHOTT Colored Glass Bandpass Filters SCHOTT Colored Glass Bandpass Filters
  • 16 Standard SCHOTT Glass Types
  • Standard Circular and Square Sizes with 1, 2, or 3mm Thickness
  • UV, Visible, and IR Bandpass Regions
SCHOTT Colored Glass Heat Absorbing Shortpass Filters SCHOTT Colored Glass Heat Absorbing Shortpass Filters
  • SCHOTT KG Colored Glass Substrates
  • Absorb Infrared Radiation
  • Standard Sizes with 1, 2, or 3mm Thickness
SCHOTT Colored Glass Longpass Filters SCHOTT Colored Glass Longpass Filters
  • 27 Standard SCHOTT Color Glass Types
  • Cut-On Wavelengths in the UV, Visible, or NIR
  • Standard Circular and Square Sizes with 1, 2, or 3mm Thickness
SCHOTT Harsh Environment Colored Glass NIR Cut-Off Filters SCHOTT Harsh Environment Colored Glass NIR Cut-Off Filters
  • High Absorption in the NIR
  • Designed for Use in Harsh Environments with High Humidity
  • 50 x 50mm Size with 1mm Thickness
SCHOTT D263&reg; T eco Windows SCHOTT D263® T eco Windows
  • Thin 0.4mm SCHOTT D263® T eco Substrates
  • Excellent Glass Alternative to Plastic Optics
  • Ideal for Weight and Space Sensitive Applications
SCHOTT Matte Colored Glass Filter Plates SCHOTT Matte Colored Glass Filter Plates New
×
SCHOTT Calibrated Neutral Density (ND) Filters SCHOTT Calibrated Neutral Density (ND) Filters New
×
  • Calibrated for Specific Wavelengths
  • Optical Densities Ranging from 0.3 to 3.0
  • NG3, NG4, NG5, NG9, or NG11 Glass Types
SCHOTT NG Gray Glass Neutral Density (ND) Filters SCHOTT NG Gray Glass Neutral Density (ND) Filters
  • Tightly Controlled Thickness Specifications
  • Standard Thicknesses of 1, 2, and 3mm
  • Even Light Attenuation in the Visible Spectrum
  • NG1, NG3, NG4, NG5, NG9 and NG11 Glass Types Available
  • Precision SCHOTT NG Glass Filters Also Available
SCHOTT NG Absorptive Neutral Density (ND) Filters SCHOTT NG Absorptive Neutral Density (ND) Filters
  • Tightly Controlled Transmission Specifications
  • NG4, NG9, or NG11 Glass Types
  • Specified Optical Densities from 0.15 to 5.0
  • Provide Even Light Attenuation in the Visible Spectrum
  • SCHOTT NG Gray Glass Also Available
SCHOTT EasyLED Series Illuminators SCHOTT EasyLED Series Illuminators New
×
  • Ringlight, Backlight, and Spotlight Illuminators
  • Integrated Controllers for Intensity Adjustment
  • Designed for Easy Integration into Microscopy Systems
SCHOTT VisiLED UV Ringlights SCHOTT VisiLED UV Ringlights
  • Switch Between Bright-Field and UV Illumination
  • Maximum UV Illuminance up to 160 W/m2
  • Actively Controlled LED Temperature
  • Five Segment Modes (Full, Semi, Quarter-Circle, Dual-Segment, Four-Segment)
