1951 USAF Resolution Calculator

View All Technical Tools

Determine limiting resolution of an optical or imaging application setup. Calculator uses relationship between group number and element number to determine resolution in terms of line pairs per millimeter.

Enter your Information

Group Number:

Element Number:

Results

Resolution (lp/mm): --

Focal Length Calculator

Equations and Corresponding Legend

$$ \text{Resolution} = 2^{\left( \text{Group Number} + \frac{ \text{Element Number} - 1 }{6} \right)} $$
