Aspheric Manufacturing

  • Manufacturing in US and Singapore

  • Stock and Custom, from Design and Prototype to Volume Production

  • Build-to-Print Capabilities

  • Over 600 Aspheric Lens Designs Available for Immediate Delivery

  • MRF Fine Finishing Consistently Exceeding λ/40 Surface Accuracy

Edmund Optics® is a recognized leader in aspheric lens manufacturing, with extensive experience producing aspheric lenses for ophthalmic instruments, surgical devices, analytical instruments, and defense applications. Edmund Optics®’ high volume aspheric lens manufacturing cell operates 24 hours a day to produce thousands of precision aspheric lenses per month. Our manufacturing cells feature state-of-the-art production and metrology equipment, which complements our expert knowledge in aspheric lens design and manufacturing. Whether your application calls for a stock component from our vast inventory, a build-to-print lens, or a fully customized design effort, our expert optical design and manufacturing engineers can develop solutions to meet your needs. Contact us today to speak with an expert or receive an expedited quote.

The Making of an Aspheric Lens

Edmund Optics® manufacturers millions of optics every year throughout our four global facilities. Join us as we take you through the creation of an aspheric lens, from molding to grinding to polishing, centering, and metrology.

Capabilities

Edmund Optics® is a premier manufacturer of aspheric lenses. We are experienced in achieving precision quality with a wide variety of Schott, Ohara, and CDGM glass types as well as fused silica and a variety of crystalline materials. Our extensive manufacturing capabilities include CNC polishing and magneto-rheological (MRF) finishing, all supported by world-class metrology that includes surface profilometry and aspheric stitching interferometry (ASI). More complicated freeform lenses with complex geometries can also be manufactured upon request.

Whether your needs call for just a few aspheric lenses for prototyping, a few dozen for pre-production, or a large volume for full production, Edmund Optics® wants to ensure your project is successful.

Aspheric Manufacturing Capabilities
  Commercial Precision High Precision
Diameter 10 – 200mm 10 – 200mm 10 – 200mm
Diameter Tolerance +0/-0.100mm +0/-0.025 +0/-0.010
Asphere Figure Error (P - V) 3μm 1μm <0.06μm*
Vertex Radius (Asphere) ±0.5% ±0.1% ±0.05%
Sag 25mm max 25mm max 25mm max
Typical Slope Error 1μm per 1mm window 0.35μm per 1mm window 0.15μm per 1 mm window
Centering (Beam Deviation) 3 arcmin 1 arcmin 0.5 arcmin
Center Thickness Tolerance ±0.100mm ±0.050mm ±0.010mm
Surface Quality (Scratch Dig) 80–50 40–20 10–5
Aspheric Surface Metrology Profilometry (2D) Profilometry (2D & 3D) Interferometry

* 1/10th wave at 632.8nm, limited by design and/or metrology

Learn about Coatings

Manufacturing Equipment

Metrology

Aspheric Equipment

Related Paper | Mid-Spatial Frequency Errors of Mass-Produced Aspheres
